Optimer® LG EVO

Optimer® Low Front LG EVO

Energy optimized plug-in multideck with maximized display area

BENEFITS AT A GLANCE

  • Excellent energy efficiency leading to label A
  • Quick return on investment
  • Plug & play connectivity options to various store gateways
  • 3M1 temperature class for a wide product range

  • SYSTEM:

    Plug-in

  • TEMP. CLASS:

    M1

  • REFRIGERANT:

    R290

  • ENERGY LABEL:

Optimer® Low Front LG EVO – Energy optimized plug-in multideck with maximized display area



Introducing the Optimer® Low Front LG EVO our energy label A refrigerated multideck – the ideal solution for hypermarkets, supermarkets, and small stores. Optimized floor space productivity through slim design that ensures generous product presentation and easy access.

Equipped with a cutting-edge energy-saving technology, our refrigerated multideck significantly reduces its energy consumption compared to the standard Optimer® LG model.

This multideck offers seamless connectivity solutions for real-time monitoring and efficient remote management. Protect the environment by reducing your carbon footprint while maintaining product freshness. Choose our eco-friendly multideck to enhance efficiency, save costs, and support sustainable business practices in any retail setting.

Key Features

Standard Configuration

  • Painted panels galvanized steel with hard-wearing powder coated finish, FA0605 white interior, FA0633 nimbus grey exterior
  • Horizontal stripe in the canopy panel as unique design marker to distinguish Optimer LG EVO from normal Optimer LG
  • Panorama endwalls
  • Integrated plastic front bumper, FA0632 statusgrey
  • Temperature-assured forced-air cooling with honeycomb air outlet
  • Energy optimized fans
  • 5 Display shelves and 40mm scanner price rails at shelves and at bottom deck
  • Premium LED 4000 K neutral white canopy lighting
  • Double glass door, tempered
  • Electronic controller
  • Sliding condensing unit
  • Condenser filter
  • Floor close-off seal at both lateral sides and front side
  • Natural refrigerant R290 (propane)

Customization

  • Transparent doors with or without antireflex coating
  • Solid endwalls or no endwalls for multiplexing
  • Multiplex kits: side by side kit and transparent plexi partition, back to back kit and side covers, possible up to 2*X block installations
  • Rear wall panelling
  • Regural castors or heavy duty castors with reinforeced bottom
  • Top mirror and lateral mirror trim covers
  • Sound absorbing package
  • Display baskets and wire dividers
  • Double side painted display shelves
  • Heavy duty display shelves
  • Price rail holder versions
  • 50 or 100mm plexi or wire risers for display shelves (front stop)
  • LED selection for vertical or horizontal shelf and front shelf lighting
  • Country specific mains cable
  • Connectivity options to various store gateways
  • Ambient light sensor for automatic light on / off switch
  • Inox visible panels, corrosion protection kit, inox return air grill
  • Endwall front profile extension kit

Dimensions

Optimer® Low Front LG EVO2 Unit 0948 LG EVO 1348 LG EVO 1948 LG EVO
Temperature [°C] -1…+1 -1…+1 -1…+1
Refrigerant R290 R290 R290
Width [mm] 885 1250 1875
Depth [mm] 840 840 840
Height [mm] 2040 2040 2040
Volume [l] 521 875 1163
Total display area [m²] 2,30 2,88 3,89
Energy consumption** [kWh/d] 3,46 4,14 5,41
Average heat dissipation [W] 144 173 225
Temperature class* M1 M1 M1
*At climate class 3 according to ISO 23953 | **Measured in accordance with the applicable EU delegated regulation
1 Energy Labels might change depending on cabinet configuration and are based on R290 plug-in refrigerant technology
2 All technical data includes LED lighting consumption where applicable
