Areor® Stepped G

Areor® Stepped G

Plug-in counter island with minimized energy consumption and maximized transparency

BENEFITS AT A GLANCE

  • Quick return of investment thanks to outstanding energy efficiency, labelled A
  • Highly transparent design for a modern and optimal product presentation
  • Plug & play connectivity options to various store gateways
  • 3M1 temperature class for a wide range of product applications
  • SYSTEM:

    Plug-in

  • TEMP. CLASS:

    M1

  • REFRIGERANT:

    R290

  • ENERGY LABEL:

Refrigerated Self-Service Counter Island – Low Energy Consumption | High Transparency

Our state-of-the-art refrigerated self-service counter islands combine exceptional energy efficiency with modern design. Featuring an A-rated energy label, the Areor® Stepped G cabinets ensure low energy consumption, helping you reduce operational costs while maintaining optimal refrigeration performance.

The sleek and high-transparency glass panels provide exceptional product visibility, inviting customers to easily access goods. Ideal for grocery stores, convenience shops, and food service areas, this unit seamlessly blends functionality with eco-conscious technology.

Designed to make a strong first impression.

Key Features

Standard Configuration

  • Highly transparent stepped plug-in counter-island for promotional sales
  • Stepped superstructure with acrylic sidewalls and one (Areor® SD) or two (Areor® ST) adjustable glass shelves
  • Bottom shelf and plinth of galvanized steel with powder-coated finish, sidewalls and front air deflectors of PVC, outside and inside color black (RAL 9005)
  • Stainless steel bumper (Areor® ST 1052 G)
  • Plinth of galvanized steel with powder-coated finish, cabinet body (PVC), outside and inside color black
  • Energy optimized fans
  • Electronic controller
  • Digital thermometer (solar)
  • Factory installed castors
  • Sliding condensing unit
  • Natural refrigerant R290 (propane)

Customization

  • Connectivity options to various store gateways
  • LED lighting for canopy and shelves, light color Neutral White 4000K, Cool White 5700K, Fresh red
  • Price rails, 40 and 60 mm
  • Large selection of CCR-certified powder coating colors internally and externally
  • Wooden cladding
  • Multiplex kit back-to-back
  • Stainless steel bumper (Areor® SD/ST 1253 G)
  • Transparent product dividers and presenter, V or Z shaped
  • Cabinet feet
  • Remote CO2 version (on request)

Dimensions

Areor® Stepped2 Unit SD 1253 G ST 1253 G ST 1052 G
Temperature [°C] -1…+1 -1…+1 -1…+1
Refrigerant R290 R290 R290
Width (without / with bumper) [mm] 1290 / 1410 1290 / 1410 – / 1020
Depth (without / with bumper) [mm] 1080 / 1150 1080 / 1150 – / 1045
Height [mm] 1150 1280 1240
Volume [l] 205 254 21
Total display area [m²] 2,02 2,66 2,0
Energy consumption** [kWh/d] 2,37 3,53 3,4
Average heat dissipation [W] 99 147 145
Temperature class* M1 M1 M1
* At climate class 3 according to ISO 23953 | ** Measured in accordance with the applicable EU delegated regulation
1 Energy Labels might change depending on cabinet configuration and are based on R290 plug-in refrigerant technology
2 All technical data includes LED lighting consumption where applicable
